2548H
Technical
- Insulation Range
- 5 - 5,000 MΩ | 50kΩ - 50 MΩ
- Insulation Accuracy
- +/- 5%
- Applied Voltage
- 10VDC
- Current
- 50nA maximum
- Indicator Range
- 0 - 1,100 µA
- Indicator Accuracy
- +/- 1%
- Capacitance Bridge Range
- 0 - 999.9 pF
- Capacitance Bridge Accuracy
- +/- 0.1%
- Capacitance Bridge Signal
- 400 Hz at 5.7 V RMS Nominal
- Capacitance Simulators Tank Range
- 0 - 999.9 pF
- Capacitance Simulators Accuracy
- +/- 0.1%
- COMP Range
- 10 - 400 pF
- Maximum Input
- 75 V RMS | 220V
- Input Power
- Four 9V batteries
- External Power
- 115V or 230V | 50 - 400 Hz AC optional
- Length
- 10.4 in
- Width
- 12.2 in
- Height
- 5.3 in
- Weight
- 7 lb
Details
- Measures capacitance of individual or interconnected tank units or unit simulators
- Measures insulation resistance of wiring, tank units, or other discrete components
- Simulates capacitance representative of empty, partially full or full tank units or systems
- Low battery drain circuitry
- Two terminal megohmmeter with six selectable test points
- Three terminal megohmmeter
