260
Technical
- DC Voltage Range
- 250mV | 2.5V | 10V | 25V | 50V | 250V | 500V | 1,000V
- DC Voltage Accuracy
- 2% of full scale
- DC Voltage Sensitivity
- 20KΩ per volt
- AC Voltage Range
- 2.5V | 10V | 25V | 50V | 250V | 500V | 1,000V
- AC Voltage Accuracy
- 3% of full scale
- AC Voltage Sensitivity
- 5KΩ per volt
- Decibel
- -20 to +50dB
- AC Current
- Up to 250 AC amperes with clamp adapter
- DC Current Range
- 50µA | 1mA | 10mA | 100mA | 500mA | 10A
- DC Current Accuracy
- 1.5% of full scale 50µA | 2% of full scale
- Rated Circuit-To Ground Voltage
- 100V AC/DC Max
- Batteries
- 1.5V D, 9V
Details
- Durable ABS plastic case provides impact resistance and drop protection
- Bright yellow housing for enhanced visibility and safety awareness
- Self-shielding taut-band meter movement provides added shock resistance
- Large, tri-colored dial with mirrored scale to prevent parallax error
- More than 20 measurement ranges for DC voltage and current, AC voltage and current, resistance
