Electrical Input
- kVA Rating
- 90 (72 kW)
- Amperage
- 100 at 460VAC | 118 at 400 VAC | 78 at 600 VAC
- Frequency
- 60 Hz
- Amperes (rated load)
- 78 Amps
- Voltage Range (maximum)
- 510 - 690
- Starting Current
- Less than 100% full load input current
- Power Factor
- More than 0.98 lagging from 10% to full load
Electrical Output
- kVA Rating (continuous)
- 90 (72 kW)
- Voltage VAC
- 115/200
- Frequency
- 400 Hz
- Amperes (at rated load per power ratings)
- 260 Amps
- Overload Trips
- at 125% after 10 minutes | at 150% after 30 seconds | at 200% after 10 seconds
- DC Content
- Less than 100 mV
- Frequency Drift
- ± 0.05%
- Phase Displacement
- 120° ± 1.5°
- Voltage adjustment range
- ± 15% of rated voltage
Dimensions
- Length
- 60 in
- Depth
- 50.1 in
- Height
- 18 in
- Weight
- 1040 lb
