EC-2665
Technical
- Rated Capacity
- 100,000 lb
- Rated Output
- 2 mV/V typical
- Non-Repeatability
- <0.05%
- Zero Balance
- +/- 10%
- Input Impedance
- 400 ohms typical
- Output Impedance
- 350 ohms typical
- Excitation Voltage (Typical)
- 10 VDC or VAC rms
- Excitation Voltage (Maximum)
- 15 VDC or VAC rms
- Insulation Resistance
- 5,000 meg ohms @ 50VDC
- Maximum Load (Safe)
- 150% F.S.
- Maximum Load (Ultimate)
- 200% F.S.
Details
- Alloy Steel
