Technical
- Voltage
- 28.5 VDC
- Output Rating
- 15.7 kW
- Rated Load Capacity (28.5 VDC)
- 550 Amps Continuous
- Starting Current Capacity
- 2,00 Amps Maximum
- Current Limiting Capability
- 300 to 2,000 Amps Continuously Adjustable
- Operating Speed
- 2,000 RPM
- Engine
- Perkins Diesel Model 4.236
- Length
- 75.5 in
- Width
- 55 in
- Height
- 63.75 in
- Weight
- 2,410 lb
Details
- 4-cylinder, 4-stroke, direct injection engine
- "Soft-Start" feature for current limiting
- Pneumatic tires
- All welded steel frame with weather-resistant canopy
- Low oil pressure protection
- High water temperature protection
