UDC-620M
Technical
- Input Voltage
- 208-240V | 380-480V
- Input Frequency
- 50 - 60 Hz
- Phase Rotation
- Any
- Input Protection
- Over/undervoltage | Loss of phase | Overcurrent | Short circuit
- Inrush Current
- No greater than 100% of full load current
- Output Full Rated Load
- 600A
- Engine Start Capacity
- 1,600A (35 seconds) | 2,000A (30 seconds)
- Output Voltage
- 28VDC
- Output Overload
- 1,000A for 1 minute
- Current Limit Adjust
- 150A to full rated current
- Output Protection
- Overload | Short circuit | Over voltage | Safety disconnect
- Power Regulation
- 10%
- Acoustical Noise
- < 65 dBA maximum at 5 ft
- Temperature Range
- -40°F - 131°F
- Relative Humidity
- 10 - 95%, Non-Condensing
- Ingress of Water
- Type 3RX, IP55
- Cooling
- Forced Convection
- Length
- 38 in
- Width
- 35 in
- Height
- 38 in
- Weight
- 340 lbs
Details
- 3 Phase
- IP55
- Indoor/Outdoor use
- Automatic input line monitoring
- 8,000 event log / diagnostics
- Emergency power "OFF" switch
- 18" hazard area clearance
- Voltage and Current Monitoring
- Elapsed time meter
- Front panel voltage adjust
- Front panel summary fault indicators
- Input & output cable racks
- Input high voltage transient protection
- Digital touchscreen display
